Page 18
1-10
3120673
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
53
Pin Options:
1
4842621
Prior to October 1994
3422401
October 1994 to Present
54
O-Ring Options:
2
Not Required
Fixed Axle
Oscillating Axle
Not Required
Prior to October 1994
3780183
October 1994 to Present
55
Valve, Relief Options:
1
Not Required
Prior to October 1994
4640812
October 1994 to Present
56
Bar, Axle Block Options:
2
0361953
Fixed Axle
Not Required
Oscillating Axle
57
Bar, Axle Block Options:
2
0361954
Fixed Axle
Not Required
Oscillating Axle
FRONT AXLE INSTALLATION - 4WD MACHINES
WITH FIXED AXLE (VARIABLE PARTS)
Ref.
0253174
BUILT PRIOR TO OCTOBER 1994
Ref.
—
0255076
BUILT OCTOBER 1994 TO PRESENT
Ref.
B
FRONT AXLE INSTALLATION - 4WD MACHINES
WITH OSCILLATING AXLE (VARIABLE PARTS)
Ref.
0250334
BUILT PRIOR TO SEPTEMBER 1990
Ref.
E
0251329
BUILT SEPTEMBER 1990 TO OCTOBER 1994
Ref.
D
0255070
BUILT OCTOBER 1994 TO PRESENT
Ref.
—
61
Front Axle Weldment Options:
1
4843447
Prior to October 1994
4844849
October 1994 to Present
0961029
Bushing, Bronze
4
62
Lockout Cylinder Assembly Options (See Section 5
for Breakdown):
2
Not Required
Fixed Axle
Oscillating Axle
1681785
Prior to September 1990
1682406
September 1990 to June 1992
1682757
June 1992 to October 1994
63
Pin Options:
1
4842621
Prior to October 1994
3422401
October 1994 to Present
64
O-Ring Options:
2
Not Required
Fixed Axle
Oscillating Axle
Not Required
Prior to October 1994
3780183
October 1994 to Present
FIGURE 1-2. FRAME, STEERING AND AXLE INSTALLATIONS - 2WD AND 4WD (WITH 4 WHEEL
STEER) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
