3120673 5-25
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-8. TELESCOPE CYLINDER ASSEMBLY - MAIN BOOM (STANDARD PARTS)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
TELESCOPE CYLINDER ASSEMBLY - MAIN BOOM
(STANDARD PARTS) Ref.
1 Not Used
2 4640495 Cartridge, Valve (Machines Built Prior to June 1990) 1
4640634 Cartridge, Valve (Machines Built June 1990 to Present) 1
2900770 Seal Kit - 4640495 and 4640634 Valves 1
3 1120108 End Cap 1
0100035 Loctite #222 A/R
4 1681283 Head 1
5 Kit Ring, Wear 1
6 Kit Seal, Wiper 1
7 Kit Seal, Rod 1
8 Kit O-Ring 1
9 4563330 Spacer, Tube 1
3951603 Setscrew 3/8"-16NC x 3/8" 2
0100011 Loctite #242 A/R
10 3480092 Piston 1
11 0100011 Loctite #242 A/R
0100038 Primer, Locking A/R
12 3900170 Setscrew 1/4"-20NC x 3/8" 2
13 Kit O-Ring 1
14 Kit Ring, Guidelock 2
15 Kit Seal, Piston 2
16 1681883 Rod Assembly 1
17 Not Used
18 2200222 Plug 1/4" 2
0100020 Sealant, Pipe A/R
— — — — — — — — — —
2900396 Seal Kit (Includes Items 5,6,7,8,13,14 and 15)
TELESCOPE CYLINDER ASSEMBLIES - MAIN
BOOM (VARIABLE PARTS) Ref.
1681880 PRIOR TO JUNE 1991 Ref. B
1682492 JUNE 1991 TO PRESENT Ref. A
51 Barrel Options: 1
1681881 Prior to June 1991
1682493 June 1991 to Present
52 Nut, Hex Options: 1
3300282 Prior to June 1991
3300286 June 1991 to Present
53 Plug Options: A/R
2200201 Plug 1/8" (Prior to June 1991) 2
2180527 Plug 1/16" (June 1991 to Present) 4
54 Cartridge, Valve Options: 1
Not Required Prior to June 1991
4640495 June 1991 to Present
2900770 Seal Kit - 4640495 Valve 1
