JLG 40HA ANSI Parts Manual - Manual (Page 292)

7-4 3120673
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
0253816 Fuel Indicator Light Electrical Diagram Ref.
4360265 Switch, LPG 1
2920026 Lamp, Indicator
3252269 Nameplate - LP Light
4931941 Headlights and Taillights Electrical Diagram Ref. E
3740049 Relay, Bosch - SPDT (At Ground Control Box) 1
4360199 Switch, Toggle (At Platform Console Box) 1
3251019 Nametag - Light On 1
1060016 Cable, Electrical - 16/3 A/R
2920019 Taillight/Clearance Light 2
3740002 Relay, Power 1
0251619/
1281525
Panel Lights Electrical Diagram (Standard Bang-
Bang and Proportional Controls) Ref. A/D
0251690 Panel Lights Electrical Diagram (Hydraulic Con-
trols) Ref. B
2920024 Light, Panel 3
4931943 Worklights Electrical Diagram (Prior to November
1992) Ref.
4360232 Breaker, Circuit - 15 Amp 1
2920013 Worklight 2
0253987 Worklights Electrical Diagram (November 1992 to
Present) Ref. C
2920111 Worklight, Halogen 2
0253393 Oil Cooler Electrical Diagram Ref. —
4921529 Harness 1
4360181 Switch, Temperature 1
Platform Electrical Diagrams Options Ref.
1281356* Bang-Bang (Standard) Controls: Ref. F
4932007 Platform Electrical Diagram - Deutz/Ford 2WS Ref. E
4932375 Platform Electrical Diagram - Deutz/Ford 4WS Ref. A
4932074 Platform Electrical Diagram - Kubota 2WS Ref. C
4932376 Platform Electrical Diagram - Kubota 4WS Ref. A
1540002 Capacitor 1000MFD/25VDC 1
3990010 Diode - 6 Amp A/R
Use 1060515 Cable, Electrical - 12/4 (To Footswitch) (was p/n
1060309) 8 ft./2.4m
Hydraulic Controls: Ref.
4932054* Platform Electrical Diagram Ref. B
3990010 Diode - 6 Amp 1
1540002 Capacitor - 1000MFD/25VDC 1
Use 1060515 Cable, Electrical - 12/4 (To Footswitch) (was p/n
1060309) 8 ft./2.4m
FIGURE 7-1.ELECTRICAL DIAGRAM LIST
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
