2-62 3120673
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
40 0901635 Bracket, Mounting - Engine (Front) 1
41 0080092 Adapter, Carburetor 1
42 3911012 Bolt #10-24NC x 3/4" 2
43 4761000 Lockwasher #10 8
44 3841049 Rod, Throttle 1
45 3321401 Nut, Jam 1/4"-20NC 2
46 1660157 Balljoint 2
47 3311801 Nut 1/2"-13NC 2
48 2220273 Fitting, Reducer 1
49 2180360 Fitting, Tee 1
50 Oil Pressure Sender Options: 1
2420033 Sender (Prior to May 1990)
2420131 Sender (May 1990 to Present)
51 Not Used
52 3790152 O-Ring 1
53 1320014 Clamp, Hose 4
54 3620027 Radiator 1
55 Bracket, Filter Options: 1
0901664 Prior to S/N 43319
0902184 S/N 43319 to Present
56 2720341 Hose, Air Cleaner 1
57 1320058 Clamp, Hose 1
58 Temperature Sender Options: 1
2420118 Sender (Prior to May 1990)
2420130 Sender (May 1990 to Present)
59 0100011 Loctite #242 (Not Shown) A/R
60 4360037 Switch, Oil Pressure 1
61 Not Used
62 Not Used
63 0630360 Bolt, Carriage 1
64 4761500 Lockwasher 5/16" 1
65 3311501 Nut 5/16"-18NC 1
FORD ENGINE ASSEMBLIES (VARIABLE PARTS): Ref.
0250040/
0250588
STANDARD BANG-BANG PROPORTIONAL CON-
TROLS AND WITHOUT NOISE REDUCTION
PACKAGE (MACHINES BUILT PRIOR TO MAY
1993) Ref. H/I
0250851/
0250902
HYDRAULIC CONTROLS AND WITHOUT NOISE
REDUCTION PACKAGE (MACHINES BUILT
PRIOR TO MAY1993) Ref. H/I
70 Pump Assembly Options: 1
Standard Bang-Bang:
3600165 Pump - Vickers (Not Field Serviceable) (Rec-
ommend using 3600199 as Replacement)
(Prior to May 1990)
2900660 Shaft Seal Kit - 3600165 Pump
3600172 Pump - Barnes (See Figure 2-22 for Break-
down) (May 1990 to January 1993)
FIGURE 2-17. FORD ENGINE INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
