1-12
3120673
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
126
4130161
Spindle (Left Side)
1
0961778
Bushing, Excel
2
127
0630425
Bolt 1"-8NC x 3 3/4"
2
128
3450606
Pin, Cotter 3/16" x 1 1/2"
1
129
3431622
Pin, Clevis 1" x 2 3/4"
1
130
Not Used
131
Not Used
132
0100011
Loctite #242 (Not Shown)
A/R
133
2160003
Fitting, Grease - 45°
2
134
0560714
Block, Tie-Rod (Left Side)
1
135
3300229
Nut, Jam 1 1/4"-12NF LH (Left Side)
1
136
3450810
Pin, Cotter 1/4" x 2 1/2"
2
137
4640812
Valve, Relief (After February 1994)
2
138
3780183
O-Ring (After February 1994)
4
139
3323403
Nut, Slotted 1 1/2"-6NF (Prior to May 1994)
2
3313403
Nut, Slotted 1 1/2"-6NC (May 1994 to Present)
2
STEERING AND SPINDLES INSTALLATION - 4WD
FRONT AND ALL REAR STEER (STANDARD
PARTS)
Ref.
201
4130221
Spindle (Front Right Side and Rear Left Side)
1
202
4130222
Spindle (Front Left Side and Front Right Side)
1
203
1681555
Steer Cylinder Assembly (See Section 5 for Break-
down)
1
204
3841018
Tie-Rod
1
205
0560714
Block, Tie-Rod (Left Side)
1
206
3300229
Nut, Jam 1 1/4"-12NF (Left Side)
1
207
0560605
Block, Tie-Rod (Right Side)
1
208
3323002
Nut, Jam 1 1/4"-12NF
1
209
3300175
Locknut
3
210
0440091
Bearing, Thrust
3
211
2160002
Fitting, Grease
4
212
2160003
Fitting, Grease - 45°
4
213
0440161
Bearing, Thrust
4
214
Cover Options:
4
3530244
(Prior to August 1992)
3536411
(August 1992 to Present)
215
Fastener Options:
A/R
0641404
Bolt 1/4"-20NC x 1/2" (Prior to August 1992)
2080026
Stud, Drive (August 1992 to May 1994)
4300106
Stud, Drive (May 1994 to Present)
216
4761400
Lockwasher 1/4" (Prior to August 1992 Only)
8
217
3431622
Pin, Clevis
1
218
4712600
Flatwasher 1"
1
219
3450606
Pin, Cotter 3/16" x 1 1/2"
1
220
0641608
Bolt 3/8"-16NC x 1"
8
221
4751600
Flatwasher 3/8"
8
222
1380124
Clip, Retainer
8
FIGURE 1-2. FRAME, STEERING AND AXLE INSTALLATIONS - 2WD AND 4WD (WITH 4 WHEEL
STEER) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
