2-78 3120673
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
42 1120218 Raincap 1
43 3220076 Muffler 1
44 1320020 Clamp, Muffler 2
45 4843691 Pipe, Exhaust 1
4100025 Sleeve, Exhaust 2.5 ft.
46 2720084 Elbow, Rubber 2
47 1320031 Clamp 5
48 4564685 Tube, Air Intake 1
49 1320026 Clamp, Muffler 1
50 4564696 Tube 1
51 Air Cleaner Assembly (Supplied with Engine - Refer to
Engine Dealer for Parts) 1
3538254 Spacer (Not Shown - Located Under Bracket) 1
52 0641408 Bolt 1/4"-20NC x 1" 2
53 4711400 Flatwasher 1/4" Narrow 2
54 4761400 Lockwasher 1/4" 2
55 3311401 Nut 1/4"-20NC 2
56 3980007 Seat, Battery 1
57 0400075 Battery 1
58 0361810 Hold-Down, Battery 1
59 0630370 Rod, Hold-Down 2
60 4751600 Flatwasher 3/8" 2
61 3300029 Wingnut 3/8"-16NC 2
1380032 Clip, Battery (Welded on Part - Not Shown) 2
62 1060172 Cable, Battery (Negative to Ground) 1
63 1060273 Cable, Battery (Positive to Aux Relay) 1
64 1060149 Cable, Battery (Aux Relay to Starter) 1
65 1060099 Cable, Battery (Aux Relay to Aux Power) 1
66 1060093 Cable, Battery (Engine to Ground) 1
67 Auxiliary Pump Options: 1
3600050 Pump Assembly (Prior to April 1993)
Replacement Parts:
7004412 Coupling (Stone/Fenner Industries Version)
7004249 Coupling (John S. Barnes Version)
7000482 Motor (Stone/Fenner Industries Version)
7004248 Motor (John S. Barnes Version)
7004414 Pump (Stone/Fenner Industries Version)
7010923 Pump (John S. Barnes Version)
3600208 Pump Assembly (April 1993 to Present)
Replacement Parts:
7013711 Coupling
7013710 Motor
7013753 Brush Kit
7013712 Pump
68 0641614 Bolt 3/8"-16NC x 1 3/4" 2
69 4761600 Lockwasher 3/8" 2
70 0060023 Actuator, Adeco 1
7008804 Bellows 1
7008829 PC Board 1
7008821 Motor 1
FIGURE 2-20. KUBOTA V1200B DIESEL ENGINE INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
