2-4 3120673
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
CONTROL VALVES INSTALLATION - STANDARD
BANG-BANG (2WS) (PRIOR TO MAY 1993) (VARI-
ABLE PARTS) Ref.
0250132 CONTROL VALVES - NON-ROTATE Ref. C
0250133 CONTROL VALVES - WITH ROTATE Ref. C
51 Control Valve Assembly Options (See Figure 2-3
for Breakdown): 1
4640246 3 Stack (Non-Rotate) (Prior to August 1992)
4640646 3 Stack (Non-Rotate) (August 1992 to Present)
4640247 4 Stack (With Rotate) (Prior to August 1992)
4640645 4 Stack (With Rotate) (August 1992 to Present)
52 4640601 Control Valve Assembly (See Figure 2-4 for 1
Breakdown)
53 Not Required
54 4640543 Valve, Dump 1
7004368 Coil (Hydraforce Version)
7009745 Coil (Vickers/Modular Controls Versions)
55 Not Required
56 4640627 Valve, Flow Control 1
7001508 Seal Kit
57 2180029 Fitting 1
58 2220820 Fitting, 90° 1
59 Not Required
60 Not Required
CONTROL VALVES INSTALLATION - STANDARD
BANG-BANG (2WS) (MAY 1993 TO PRESENT)
(VARIABLE PARTS) Ref.
0253772 CONTROL VALVES - NON-ROTATE Ref. D
0253771 CONTROL VALVES - WITH ROTATE Ref. E
51 Control Valve Assembly Options (See Figure 2-3
for Breakdown): 1
4640646 3 Stack (Non-Rotate)
4640645 4 Stack (With Rotate) (Prior to January 1995)
4640909 4 Stack (With Rotate) (January 1995 to Present)
52 Control Valve Assembly (See Figure 2-4 for Break-
down) 1
4640601 (Prior to October 1993)
4640850 (October 1993 to Present)
53 Not Required
54 4640543 Valve, Dump 1
7004368 Coil (Hydraforce Version)
7009745 Coil (Vickers/Modular Controls Version)
55 4640623 Valve, Flow Control 1
56 Not Required
57 2220651 Fitting 1
FIGURE 2-1. CONTROL VALVES INSTALLATION (DEUTZ ENGINES WITH STANDARD BANG-
BANG OR PROPORTIONAL VALVES) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
