3120673 5-7
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-2. PLATFORM LEVEL CYLINDER ASSEMBLY (MACHINES BUILT PRIOR TO JANUARY
1990)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1681866 PLATFORM LEVEL CYLINDER ASSEMBLY
(MACHINES BUILT PRIOR TO JANUARY 1990) Ref. C
1682178 PLATFORM LEVEL CYLINDER ASSEMBLY
(MACHINES BUILT JANUARY 1990 TO OCTOBER
1992) Ref. C
1 1681869 Barrel Assembly 1
2 0960613 Bushing, Bronze 2
3 4640509 Valve 2
2900792 Seal Kit - 4640509 Valve 1
4 3300271 Nut, Hex (Prior to January 1990) 1
3300284 Nut, Hex (January 1990 to October 1992) 1
0100011 Loctite #242 A/R
0100038 Primer, Locking A/R
5 3900170 Setscrew 3/8"-16NC x 3/8" 1
0100011 Loctite #242 A/R
6 Kit Lock-Ring 2
7 Kit Seal, Piston 2
8 3480130 Piston (Prior to January 1990) 1
3480141 Piston (January 1990 to October 1992) 1
9 Kit O-Ring 1
10 4563771 Spacer, Tube 1
11 3900141 Setscrew 1/4"-20NC x 3/8" 1
0100011 Loctite A/R
12 Kit T-Seal 1
13 Kit Ring, Wear 1
14 1681847 Head 1
15 Kit Seal, Rod 1
16 Kit Wiper, Rod 1
17 1120336 Cap 1
0100035 Loctite A/R
18 1681867 Rod Assembly (Prior to January 1990) 1
1682177 Rod Assembly (January 1990 to October 1992) 1
19 0961254 Bushing, Bronze 2
20 2160002 Fitting, Grease 2
21 2200202 Plug 1/4" 2
2200201 Plug 1/8" 2
0100020 Sealant, Pipe A/R
— — — — — — — — —
2901103 Seal Kit (Includes Items 6,7,9,12,13,15 and 16) 1
Note: Refer to number stamped on barrel for
identification. Ref.
