1-6 3120673
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
213 0440161 Bearing, Thrust 4
214 Cover Options: 4
3530244 (Prior to August 1992)
3536411 (August 1992 to Present)
215 Fastener Options: A/R
0641404 Bolt 1/4"-20NC x 1/2" (Prior to August 1992)
2080026 Stud, Drive (August 1992 to May 1994)
4300106 Stud, Drive (May 1994 to Present)
216 4761400 Lockwasher 1/4" (Prior to August 1992 Only) 8
217 3431622 Pin, Clevis 1
218 4712600 Flatwasher, 1" 1
219 3450606 Pin, Cotter 3/16" x 1 1/2" 1
220 0641608 Bolt 3/8"-16NC x 1" 8
221 4751600 Flatwasher 3/8" 8
222 1380124 Clip, Retainer 8
223 4920096 Wire, Safety 4 ft./
1.22m
0250085 STEERING AND SPINDLES INSTALLATION - 4WD
DOMESTIC MACHINES (VARIABLE PARTS) Ref. E
0252333 STEERING AND SPINDLES INSTALLATION - CSA
4WD MACHINES (VARIABLE PARTS) Ref. B
251 Kingpin Options: 4
3421190 Standard
3421887 CSA
B
FIGURE 1-1. FRAME, STEERING AND AXLE INSTALLATIONS - 2WD AND 4WD (WITH 2 WHEEL
STEER) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
