3120673 5-15
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-5. LIFT CYLINDER ASSEMBLY - MAIN BOOM (STANDARD PARTS)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
LIFT CYLINDER ASSEMBLY - MAIN BOOM (STAN-
DARD PARTS) Ref.
1 Not Used
2 1681841 Rod
0960946 Bushing, Bronze 2
3 1120340 Cap 1
4 1681843 Head 1
5 3480102 Piston 1
6 Not Used
7 4563769 Spacer 1
8 Not Used
9 Kit Wiper, Rod 1
10 Kit Seal, Rod 1
11 Kit Ring, Wear 1
12 Kit T-Seal 1
13 Kit O-Ring 1
14 Kit Ring, Lock 2
15 Kit Seal 2
16 3900170 Setscrew 3/8"-16NC x 3/8" (February 1991 to Present) 1
3951403 Setscrew 1/4"-20NC x 3/8" (Prior to February 1991) 1
17 3951402 Setscrew 1/4"-20NC x 1/4" 1
18 Not Used
19 Not Used
20 0100020 Sealant, Pipe A/R
21 0100011 Loctite #242 A/R
22 2160001 Fitting, Grease - 90° 1
23 Not Used
24 0100035 Loctite A/R
25 0100038 Primer, Locking A/R
26 Not Used
27 0100034 Loctite A/R
28 2160003 Fitting, Grease - 45° 1
— — — — — — — — — —
2901102 Seal Kit (Includes Items 9-15) 1
1682124 LIFT CYLINDER ASSEMBLY (PRIOR TO OCTOBER
1992) (VARIABLE PARTS) Ref. E
9983275 LIFT CYLINDER ASSEMBLY - 8 FT. PLATFORMS
(PRIOR TO OCTOBER 1992) (VARIABLE PARTS) Ref. A
51 1682125 Barrel 1
0961422 Bushing, Bronze 2
52 3300190 Nut (Prior to February 1991) 1
3300281 Nut (February 1991 to Present) 1
3300323 Nut (Cylinder - p/n 9983275 Only) 1
53 4640634 Valve, Cartridge 1
2900770 Seal Kit - 4640634 Valve 1
54 2200233 Plug, Pipe 3/8" 4
