SECTION 6
HYDRAULIC
S
E
C
T
I
O
N
6
H
Y
D
R
A
U
L
I
C
2791693
Ford/Kubota Proportional Controls (Prior to June
1992)
2791959
Ford/Kubota Proportional Controls (June 1992 to
May 1993)
2792004
Ford/Kubota Proportional Controls (May 1993 to
Present)
2791664
Ford/Kubota Proportional Controls (May 1993 to
Present)
2791956
Hydraulic Controls (June 1992 to May 1993)
2792005*
Hydraulic Controls (May 1993 to Present)
1281326
Steer Hydraulic Diagram Without Swivel (2WS)
Ref.
2791655
2WD Fixed Axle With Standard Bang-Bang or Pro-
portional Controls
2791656
2WD Oscillating Axle With Standard Bang-Bang or
Proportional Controls
2791657
4WD With Standard Bang-Bang or Proportional Con-
trols
2791670
2WD Fixed Axle With Hydraulic Controls
2791671
2WD Oscillating Axle With Hydraulic Controls
2791672
4WD With Hydraulic Controls
1281284*
Steer Hydraulic Diagram With Swivel (2WS)
Ref.
2791625
2WD Fixed Axle With Standard Bang-Bang or Pro-
portional Control
2791626
2WD Oscillating Axle With Standard Bang-Bang or
Proportional Control
2791633
4WD With Standard Bang-Bang or Proportional Con-
trol
2791667
2WD Fixed Axle With Hydraulic Controls
2791668
2WD Oscillating Axle With Hydraulic Controls
2791669
4WD With Hydraulic Controls
1281553
Steer Hydraulic Diagram (4WS)
Ref.
2791812
2WD Fixed Axle
2791813
2WD Oscillating Axle
2791814
4WD
Tow Hydraulic Diagrams
Ref.
2791295
Prior to March 1993
2791764
March 1993 to Present
FIG & ITEM #
PART NUMBER
DESCRIPTIONHYDRAULIC DIAGRAM LIST
QTY.
REV.
