3DJH
8QSDFNLQJ
Please unpack the unit carefully and make note of any damages. It is important that
any damage that occurred during shipping be noted at once while unpacking. If
damage has occurred, you should take stock of this damage immediately (noting
whether by mail, rail or express delivery, etc.).
The following sections describe the entire range of components included with deliv-
ery, including the various system variants.
'HOLYHU\ VFRSH
3DFNDJH 3DFNDJH 3DFNDJH 'HVFULSWLRQ
1x 1x 1x Controller with measurement cell
Accessory set package 1/ 2 or 3
Operating instructions
1x 1x 2x Decomposition vessel C 50XX
1x - - Cooling system C 5001
- 1x - Cooling system C 5004
Data sheet
- - 1x Cooling system C 5002
- - 1x Measurement cell
1x 1x - O
2
-Pressure hose
Length: 2 m
Connection: 1 x M8x1, SW 10
1 x ¼“ , SW 17
1x 1x 2x Venting hose
Length: 1,5 m
Connection: 1 x M6, SW 8
- - 2x Connection piece
- - 3x Pivot plates
- - 1x O
2
- Pressure hose
Length: 2 m
Connection: 1 x M8x1, SW 10
1 x ¼“ , SW 17
- - 1x Extension for control and connection
cable
- - 2x
2x
Water hose, short
Water hose, long
