3. Ensure the tow ball is mounted correctly and
is fitted tightly.
4. Connect the tow coupling and ensure the
latching mechanism is working and has
latched.
5. Connect the break-away chain to the towing
vehicle, unset the reversing lock on the tow
coupling.
6. Check that the bolt, D-Clamp or attaching
device is able to take the rated load.
7. Connect the trailer road lights to the towing
vehicle and test that the functions work.
8. Retract the jockey wheel and place it in the
stowed position (see photograph below).
Figure 10.4 - Jockey Wheel in Stowed
position
9. Check the covers are secure and no debris
or work tools are in the platform.
Death or Serious Injury can result from
losing control of a trailer when towing.
Never tow above the rated speed marked on
the draw bar.
Never tow the unit with an under rated
vehicle. Always check manufacturers
vehicle load specifications.
page 10 - 2
MHP16/47 – 11544A
10. Stowing and Transporting
DANGER
