■ Lanyard anchor points
Figure 7.17 - Lanyard Anchor Points
Vi sually check the lan yard an chor points to see that
they are not de formed cut off or loose.
■ Platform gravity gate
Figure 7.18 - Platform Gravity Gate
■ Platform guardrails
Figure 7.19 - Platform Guardrails
Visually inspect the platform guardrails to see that
none of the tubing has been cut out, removed, or
deformed in any way.
Visually check the guardrail welds to see that none
is cracked nor ground down.
■ Flashing light (option)
Figure 7.20 - Flashing Light
Vi sually check the op tional flash ing light, to see
that the light flashes at ap prox i mately one flash per
sec ond when the mo tor key switch is turned on.
■ Ground control switches
Figure 7.21 - Ground Control Switches
With the Ground/Plat
form Se
lec
tor set to
ground:
Check that each of the plat form mov ing switches
( through to ) cause the MHP16/47 to move the
way it should.
Check both po si tions of each switch.
MHP16/47 – 11544A
page 7 - 5
7. Daily Inspection and Maintenance
