■ Overall Dimensions - MPHP16/47
MHP16/47 – 11544A page 3 - 3
3. Specifications
1
7
5
0
m
m
(5
’ 9
”)
8
7
0 m
m
(2
’ 1
0
”)
2050 mm
(7’ 9”)
6810 mm
(22’ 4”)
1680 mm
(5’ 6”)
280 mm
(11”)
1580mm
(5’ 2”)
2050 mm
(7’ 9”)
2160 mm
(7’ 1”)
525mm
(1’ 8”)
4755 mm
(15’ 7”)
6810 mm
(22’ 4”)
