1. Safety
KEEP CLEAR OF DESCENDING BOOM
DEATH OR SERIOUS INJURY CAN
OCCUR FROM DESCENDING BOOM
0150602
ALL FOUR
STABLIZERS
ALL FOUR
STABLIZERS
TYRE PRESSURE
60
p.s.i.
413 kPa
COLD
7856
ENGAGE
LATCH
CRADLE
FOR TRAVELLING
.
10036
HYDRAULIC
FLUID
LEVEL
CHECK FLUID LEVEL WITH PLATFORM LOWERED
USE PREMIUM HYDRAULIC OIL
GRADE 10W40
O
O
VISCOSITY AT 100 F (38 C)
320 SUS (SAYBOLT)
O
O
POUR POINT: -35 F (-37 C)
DO NOT OVERFILL
45177-6
FULL
ADD
302950
HYDRAULIC OIL
9207
DANGER
DO NOT ALTER OR DISABLE
LIMIT SWITCHES, SAFETY
SWITCHES, OR INTERLOCKS.
451986
x4
EMERGENCY LOWER
CONTROL INSIDE
9209
GASOLINE
0071925
6/47
1
DANGER
DO NOT ALTER OR DISABLE
LIMIT SWITCHES, SAFETY
SWITCHES, OR INTERLOCKS.
451986
IN
1.
2.
OPEN
CASE OF ENGINE FAILURE
THE
THE
GOLD MANUAL VALVE (1) TO LOWER
PLATFORM AND RETRACT
BOOMS.
ONLY WHEN THE BOOMS ARE FULLY RETRACTED
OPEN
COMPLETE
THE BLACK MANUAL VALVE (2) TO
LOWERING OF THE PLATFORM.
