3. Specifications
The Snorkelift MHP16/47 is a boom sup ported el e vat ing work plat form built to con form to all ap pli ca ble
OSHA, ANSI or CSA stan dards as pre vi ously out lined. OSHA Para graph 1910.67 Ti tle 29, C.F.R., Ve hi -
cle-Mounted El e vating and Ro tating Work Plat forms - La bour. OSHA Para graph 1926.556 Ti tle 29,
C.F.R., Ae rial Lifts - Con struc tion. Aus tra lian Stan dard AS1418-10 1996 El e vating Work Plat forms.
NOTE:
For further details regarding lubricants, maintenance schedules and service please refer to the
Maintenance and Repair parts Manual for this machine.
■ General Specifications
SPECIFICATIONS
MHP16/47
Working height
16.3m
53’ 5”
Platform height
14.4m
47’ 2”
Horizontal outreach
@ 215kg
@ 120kg
@ 80kg
7.9m
9.7m
10.5m
25’ 11”
31’ 9”
34’ 5”
Outrigger width
3.53m
11’ 6”
Transit width
1.75m
5’ 8”
Transit length
6.7
21’ 11”
Transit height
2.2m
7’ 2”
Standard colour
White booms / column. Orange base, charcoal legs
Kerb weight
1640kg
3608lbs
Platform capacity
215kg
4731lbs
Platform size
1030w x 610d x 1100h
3’ 6”w x 2’d x 3’ 7”h
Power source
220V/10A or Honda GX160 5.5HP
Gradeability
Unit can be levelled on a 5
o
slope
Maximum towing speed
80kph
50mph
Trailer tongue weight
80kg
176lbs
Insulation rating
Nil
Power in basket
Optional 220V outlet
Boom control
Proportional electric
Platform rotation
Not available
Turntable rotation
400
o
noncontinuous
Lower
46 seconds
Slew 400
o
110 seconds
C.E. Approval number
SAQ M543-96
MHP16/47 – 11544A
page 3 - 1
