7. CORRECT USE
57
ዓ. CORRECT USE
CAUTION
Turn off the power switch before installing the needle, otherwise the machine may operate if the treadle is
depressed by mistake, which could result in injury.
ዓ-ው. Installing the needle
Use a Schmetz Nm 134 needle.
1. Loosen the set screw (1).
2. Insert the needle as far as it will go so that the
groove is facing toward pulley.
3. Securely tighten the set screw (1).
[At the time of shipment]
Spec. -2
-3
Needle
134 Nm90
134 Nm75
3948Q
