HE-800A
5. OPERATION
41
No. Setting items Setting range Unit Default
36 Rear tack sideways correction (rectangle only)
-1.0 - 1.0mm 0.1 0.0
37 Rear tack vector shape(rectangle only)
1: 2: 3:
1: Triangle
2: Rectangle
3: Saw-shape 1 1
38 No. of stitches in X direction for saw-shaped rear
tack vector shape (When sewing saw-shaped
rear tack stitches for rectangular buttonholes)
2 - 14 stitches 2 4
39 No. of stitches in Y direction for saw-shaped rear
tack vector shape (When sewing saw-shaped
rear tack stitches for rectangular buttonholes)
1 - 5 stitches 1 1
40 Start backtack 0 - 6 stitches 2 2
41 Start backtack width
0.5 - 3.0mm 0.1 0.5
42 Start backtack pitch
0.10 - 0.80mm 0.05 0.30
