Do you want to use the Switched 12 volt DC source from the F/IC?

If so, connect the

“Switched 12 Volt” source wire as shown below. (Note: The

driver can handle 1 amp max.) See Figure 20.

LOW CURRENT

RELAY/SOLENOID

SW

12

FIC

Figure 20: Switched 12V

DC

connection


Do you want to use the Auxiliary Gauge in the F/IC?

If so, connect analog UEGO AEM no. 30-5130 as shown below. See Figure 21.

ANALOG UEGO

ANALOG OUT -

ANALOG OUT +

BROWN

WHITE

AU
X IN

SIG G

ND

FIC

Figure 21: Analog UEGO gauge connection

Or connect digital UEGO AEM number 30-4100 as shown below. See Figure 22.

FIC

ANALOG OUT

DIGITAL UEGO

WHITE

AU
X IN

Figure 22: Digital UEGO gauge connection
