FAA Approved Installation Manual for the
Report No 908
EDM-900 and EDM-930
Page 43 of 50 Rev J
Primary Engine Data Management System Date 5-24-2014
yel 1
red 2
J1 For 4 and 6 cylinder installations
yel 3
red 4
Aircraft engine ground lead
+12 or +24 vdc power lead
IND temperature sensor
OIL temperature sensor
TIT 1 sensor
TIT 2
sensor
Carb temperature sensor
yel 5
red 6
yel 14
red 15
yel 16
red 17
yel 18
red 19
gray 12
Remote temperature/voltage alarm light
(option)
red 13
black 25
OAT
yel 1
red 2
J1
FOR
7, 8,
and
9
cylinder installations
yel 3
red 4
Aircraft engine ground lead
+12 or +24 vdc power lead
OIL temperature sensor
TIT 1 sensor
Carb temperature sensor
yel 5
red 6
yel 22
red 23
yel 20
red 21
yel 18
red 19
gray 12
Remote temperature/voltage alarm light
(option)
red 13
black 25
CHT-7
+
yel 7
red 8
yel 9
red 10
+
+
CHT-8
CHT-9
yel 14
red 15
OAT
EGT-7
EGT-9
EGT-8
yel 16
red 17
wht 24
wht 11
DATA IN
DATA OUT
