FAA Approved Installation Manual for the Report No 908
EDM-900 and EDM-930 Page 34 of 50 Rev J
Primary Engine Data Management System Date 5-24-2014
29.13 Components Parts list for pressurized RPM sensor P/N depends on Magneto make and model
Slick 6000………………………….….P/N 420809
Bendix magneto 20, slick 600………P/N 420806
Bendix Dual ………………………….P/N 420808
Bendix 1200………………………….P/N 420807
30. Weight and Balance Data
Indicator PN 790000(-A) EDM-900 2.0 Lbs
Indicator PN 790000(-C) EDM-930 3.0 Lbs
EGT / TIT / CDT / IAT / OAT probe 2.0 oz. each / 0.125 lbs
CHT / Oil Temperature probe 1.5 oz. each / 0.094 lbs
4/6 Cylinder Harness 8 ft. 14.0 oz. each / 0.88 lbs
RPM 1.5 oz each / .094 lbs
MAP 5.0 oz / 0.42 lbs
Fuel Pressure Sender 5.0 oz / 0.42 lbs
Oil Pressure Sender 5.0 oz / 0.42 lbs
Harness each 1.0 Lbs
31. Pilot Programming
To start the Pilot Program procedure, simultaneously hold the STEP and LF buttons for five seconds. You will see the
word PROGRAM for two seconds and then the sequence shown in the chart below.
Tap the STEP button to advance to the next item in the list. Hold the STEP button to step back to the previous item.
Tap the LF button to select alternate values of that item. Simultaneously hold both STEP and LF to exit.
STEP
advances next
item
LF sequences
through these
values Comments
PROGRAM Stays on for two seconds.
FUEL N FILL ? N Tap LF to change fuel status. Exits program mode when done.
RATE 4 0 … 9 Index rate (pause time in seconds) in the Automatic Mode. 0 disables the Automatic Mode.
OAT F OAT F
 OAT
C To calibrate the OAT
10°, hold both the STEP and LF buttons simultaneously for five
seconds, which will proceed to the next step. Otherwise the next step will be skipped.
OAT
0
OAT-I0 …
OAT
I0
This step will be normally be skipped.
Adjust the indicated temperature up or down by up to 10°. For example, OAT
3 adjust
the OAT 3° higher.
EGT I?N EGT I?N

EGT I?Y Y—Yes—sets the digital display to one-degree resolution; N—No—sets 10°. (10°
resolution is easier to interpret the EGT’s.)
HPC I25 70 HP
HPC= I25 %HP display will change when HP constant is adjusted. Hold STEP and LF for 5 seconds
until you see ADJUST to set the HP calibration. Tap STEP to continue to the next step.
To adjust the MAP, hold both the STEP and LF buttons simultaneously for five seconds,
which will proceed to the next step. Otherwise the next step will be skipped.
MAP
29.9 MAP 20

32
Adjust the MAP.
KF 29.90 Adjust the instrument’s K-factor to match the fuel flow transducer K-factor.
TR IP? N TR IP? N

TR IP? Y N—No—Upon informing the EDM that you refueled the aircraft, reset total fuel used to 0.
Y—Yes—accumulate total fuel used rather than reset to 0 at each refueling. See page
DATE AND
TIME Displays the Date and time
