J.P. Instruments EDM 930 Primary Primary Installation Manual - Manual (Page 32)

FAA Approved Installation Manual for the Report No 908
EDM-900 and EDM-930 Page 32 of 50 Rev J
Primary Engine Data Management System Date 5-24-2014
29. Component Parts
Single engine
-4 Cyl -6 Cyl -7 Cyl -8 Cyl -9 Cyl
Display EDM-930 P/N 790000-C-(xxx) 1 1 1 1 1
Display EDM-900 P/N 790000-A-(xxx) 1 1 1 1 1
EGT probe KIT PN 1280 4 6 7 8 9
TIT probe with option KIT 1200 1 1 1 1 1
CHT probe KIT PN 1260 4 6 7 8 9
OAT probe with option KIT 1300 1 1 1 1 1
IAT probe with option KIT 1144 1 1 1 1 1
Carb temp probe KIT 1250 PN 500409 1 1 1 1 1
Oil Temp probe with option KIT 1255 PN 400409 1 1 1 1 1
Oil pressure sender KIT 1460 PN 159936A 1 1 1 1 1
Fuel pressure sender KIT 1450 PN 159935A 1 1 1 1 1
Fuel pressure differential sender Kit 1480 PN 159938 1 1 1 1 1
Ammeter shunt PN 159920 1 1 1 1 1
Fuel Flow transducer PN 700900-1 or -2 1 1 1 1 1
Fuel Level sender option 1 1 1 1 1
MAP KIT 1440 PN 159934A 1 1 1 1 1
RPM one of P/N 420806 or 420809 Pressurized 1 1 1 1 1
RPM one of P/N 420815-1, -2 Non Pressurized 1 1 1 1 1
RAD P/N-790749 1 1 1 1 1
29.1 Component Parts List for EGT (KIT 1280), TIT (KIT 1200) Probe
1 Thermocouple type K probe PN M-111
1 Stainless Steel Clamp Thimble
1 Stainless Steel Exhaust Seal Washer
1 Stainless Steel Screw Type Clamp
2 Ring Terminals
2 Screws and nuts 6-32 X 1/4
1 Fiberglass tube 3/8” x 5”
29.2 Component Parts list for CHT KIT 1260
1 Bayonet Probe Thermocouple type K Spring loaded PN 5050-T
2 Ring Terminals
2 Screws and Nuts 6-32 X 1/4"
1 Fiberglass tube 3/8” x 5”
29.3 Component Parts list for IAT (KIT 1300) probe
1 Thermocouple type K probe PN M-111
1 Stainless Steel Clamp &Thimble
1 Stainless Steel Exhaust Seal Washer
29.4 Component Parts list for OAT (KIT 1220) probe
1 P/N 400510, OAT probe
2 Ring Terminals
2 Screws and Nuts 6-32 X1/4"
Fiberglass tube 3/8” x 5”
29.5 Component Parts list for CARB (KIT 1190) probe
1 P/N 400128, CARB probe
