Page 66: Operation
64
Model 6042
Origin 5/02
Operation
Final Positioning Mode
With the boom above 40° (Figure 41, 1), the Stabil-TRAK System is now in
the FINAL POSITIONING MODE (2). In this mode the rear axle is
UNLOCKED and is allowed to pivot but will respond SLOWLY to changes in
terrain. The Stabil-TRAK light will be OFF (3).
The frame sway control will function normally in this mode.
To check that the Stabil-TRAK System is functioning properly, refer to the
test procedure on page 168 for the proper system function.
Figure 41
OH0724
2
3
1
