Model 6042

Origin 5/02

Operation

Travel Select Lever

(Figure 10)

The Travel Select Lever (Figure 10, 1) has three positions to select direction
of travel:

F = FORWARD ...............all the way FORWARD

N = NEUTRAL ................CENTER position

R = REVERSE................ all the way REARWARD

Figure 10

To change travel selections, move the lever FORWARD or REARWARD to
the desired selection.

When the Travel Select Lever is shifted to REVERSE, the back-up alarm will
automatically sound.

NOTE: The Travel Select Lever must be in the (N) NEUTRAL position to
permit engine starting and when boom angles are greater than 40°, shifting
into NEUTRAL activates the locked mode of the Stabil-TRAK system.

OS0340

OH1792
