Page 44: Operation
42
Model 6042
Origin 5/02
Operation
Rear View Mirrors
Two rear view mirrors are provided to aid the operator's rear vision. A
rectangular flat lens mirror (Figure 25, 1) is mounted on the upper left of the
cab (2). A convex lens mirror (3) is mounted on the right side of the frame
(4). Both mirrors are adjustable to obtain the best rear view by the operator.
Figure 25
OH1830
3
1
2
4
