Daisy Chain Connection
a)Multiple Interface System

Uses only one wire to send power, light, ground, and data to and from all seven
gauges.
All gauges and the Control Unit Ⅱ have separate microcomputer units.

b)Easy installation

Installing additional gauges involves simply connecting them to the installed
gauge and wiring the sensor to the Control Unit Ⅱ.

c)Easy operation

Gauges that are out of reach can be controlled by using the Control Unit Ⅱ at
hand.
It is possible to connect up to seven gauges to one Control Unit Ⅱ.
Using only one switch, it is possible to display memory replay,
peak memory and warning set values for all gauges.

d)Low cost

It is not necessary to purchase additional control units when installing
additional gauges.

*Daisy Chain connection cannot be applied to connection between Defi- Link

Meter BFs and Defi-Link Meters.

Common features of Defi-Link Meter BF and Defi-Link Meter
1.Stepping Motor
a)Quick response

Gauge pointers driven by stepping motor have a smooth instantaneous
response to rapid acceleration of high performance vehicles.

b)High precision and light weight

Maximum angle of deflective, 270゜is controlled by the microcomputer up to
2,300 times(0.12゜

) to provide high precision in the accuracy of information

generated.
Compared to similar products from other companies, this product is
30% lighter.

c) Freedom of installation

There is no“dumping of oil”

. The meter can be installed at any angle.

2.Multiple functions
a)When the ignition is turned on, "opening mode" automatically begins.

When the engine is started, all LED indicators light and all gauge pointers move.
The gauges perform a self-test.
