・Connect Defi-Link Meters

to METER OUTPUT1.

・Connect Defi-Link Meters

to METER OUTPUT2.

・Oil Pressure is 0kPa when

the engine is off and the
warning LED is lighted
and a buzzer sounds.

・Set the number of

cylinders refering to P.87.

・Connect tachometer to

METER OUTPUT1.

・Connect the orange wire

to the 12V wire when
ignition is on.

・Defi-Link Meters are

connected to METER
OUTPUT2.

・Defi-Link Meter BFs are

connected to METER
OUTPUT1.

・The condition is normal.

・The setup of the number

of cylinders is wrong.

・Tachometer is connected

to METER OUTPUT2.

・The orange wire (IGN) is

connected to ACC.

・Illumination of Defi-Link

Meters doesn't go out
being interlocked with
the illumination switch
off.

・Brightness of Defi-Link

Meter BF's illumination
can not be adjusted.

・Illumination of Defi-Link

Meter BF doesn't go
on.

・The warning LED of oil

pressure meter is
lighted and a buzzer
sounds when the
engine is off.

・Tachometer doesn't

work properly.

・Tachometer indicates

an abnormal value as a
peak value.

CONDITION

POSSIBLE CAUSE

REMEDY
