4．Specification
Power Supply Voltage
Current Consumption
(Maximum value in case 7 gauges are connected to the Defi-Link Control Unit Ⅱ
Operational Temperature Range
Storage Temperature Range
Display Range
Applicable Number of Cylinders
●Triple Meter Hood and Bezel
Installation of φ60 Bezel, hood, and visor
●DF05201 Single Meter Visor cannot be attached with the bezel.
DC10V∼15V(For 12V vehicles)
+B line MAX 2A (Dark current MAX 2.5mA)
IGN line MAX 0.1A
ILM line MAX 0.2A
-20 ∼ +60℃, -4 ∼ +140° F (under 80% relative humidity)
-40 ∼ +80℃, -40 ∼ +176° F (under 80% relative humidity)
Turbo
Oil Press.
Intake Manifold Press.
Fuel Press.
Oil Temp.
Water Temp.
Exhaust Temp.
Tachometer
-100kPa ∼ +200kPa
0 ∼ 1,000kPa
-100kPa ∼ +20kPa
0 ∼ 600kPa
50 ∼ 150℃
20 ∼ 120℃
200 ∼ 1,100℃
φ60, φ80
φ80, φ115
0 ∼ 9,000 RPM
0 ∼ 11,000 RPM
1・2・3・4・5・6・8
＊Applicable numbers of cylindes of DF05001 are 3, 4, 5, 6 and 8.
DF033A0
×
DF033DC
Attachable
DF03301
×
DF03302
×
DF03303
Attachable
