106
・In general the gauges
show low values.
・ The gauges don't
perform the opening
mode.
・The gauges don't
perform the opening and
ending mode.
・The WARNING LED
flashes ON at a value
different from the set
WARNING value.
・The pointer is showing
an abnormal value.
・The WARNING LED is
flashing ON and OFF.
Please refer to the table below and reconfirm before asking for repairs.
・The earth wire is not
properly fixed on the
battery minus terminal.
・A harness wire is not
installed properly.
・The fuse is blown out.
・Various harnesses are
picking up noise from
spark signals or wireless
radios etc.
・Cables are picking up
noise from spark plugs
or communication
equipment.
・There is a wire short
circuit somewhere.
・ There is a disconnected
wire.
・The sensor harness
coupler is fixed to a
different connector.
CONDITION POSSIBLE CAUSE
・Extend the earth wire of
the power harness and
connect it properly to the
battery minus terminal.
・Check wiring.
・Make sure the wiring is
not touched on the
vehicle body and then
change the fuse.
・Reposition the sensor
harness avoiding
noise.
・Confirm that no wires are
touching the vehicle
body.
・Confirm that there are no
wire broken or the
coupler is not
disconnected.
・Confirm that the sensor
harness coupler is
located in the right
position.
REMEDY
8．TROUBLE SHOOTING (for customer and installation personnel)
When abnormal conditions are found in meters, please be sure to check. Otherwise,
serious accidents may occur.
WARNING
