Features of Defi-Link Meter BF
a)1.LED illumination
Gauge dials are invisible while the ignition switch is off. Once the ignition
switch is turned on, a clear display appears by colored LED illumination.
2.Red emitting needle pointer
Gauge dial illumination and a red emitting needle pointer increase visibility.
b)1."Opening mode"
Illumination of gauge dial, needle pointer, and each LED are turned on being
interlocked with ignition switch on. After the illumination is turned on, it goes
out once and then comes back on again.
2."Closing mode"
Illumination of gauge dial, warning LED, peak LED, and needle pointer all
gradually goes out after the ignition switch is turned off.
c)1.Brightness can be adjusted. There are 5 stages of brightness in the daytime
and 5 stages in the nighttime. The brightness decreases being interlocked
with the illumination switch on.
The decrease in lights can be canceled.
b)Wiring check function
Any cut wire, short circuit, and communication errors are checked and
possible areas of fault are checked.
c)Warning function
A warning value can be set. When this value is exceeded, a red warning LED
comes on.
It is possible to connect a Defi-Link Indicator(sold separately).
d)Peak memory function
Peak values are stored and can be checked later.
3.Attractive design
a)A mounting bracket and instrument case is provided with the product.
Defi-Link gauge installation stand(Meter holder) is included with all products.
The back of each gauge is made of an attractive black case.
b)Bezel
The Bezel is hairline finish with an alumite processing which gives it a high
gloss look.
c)LED Lamps
The lights are produced from high intensity LED lamps.
