Brother PC 8500 User Manual
Page 40
1
2
2. Pass the thread underneath the presser foot and pull it out
from the rear of the machine by about 5 cm.
1
Upper thread
2
5 cm (1-15/16”)
5
3. While holding on the thread tails and the fabric with your left
hand, turn the balance wheel with your right hand to move
the needle to the sewing start position.
1
Thread
*
Sewing can begin without pulling out the bobbin thread.
5
3
4. Lower the presser foot. Press the “REVERSE STITCH”
button to sew a reverse stitch, and then press the
“START/STOP” button. The machine will start to run at slow
speed.
5
3
5. When sewing is completed, press the “REVERSE STITCH”
button to sew a reverse stitch.
5
6. Press the “THREAD CUTTER” button to cut the threads .
*6. Cut thick thread (thicker than # 30) with the cutter on the
side of the machine as illustrated.
*
BOBBIN THREAD SENSOR
If a warning message appears on the message screen, the
bobbin thread is running out. Replace the bobbin thread at
this time.
37
(Programmed
