Buffalo Technology Buffalo AirStation WLAR-L11-L - Manual (Page 38)

WLAR-L11-L Internet Connection Manual 36
Continue to the AirStation Settings section.
5
Click the Protocols tab and select “TCP/IP
Protocol”. Then click the Properties button.
6
Specify the IP address and enter the following
address.
IP address: 192.168.0.2
Subnet mask: 255.255.255.0
Click the OK button to close the window.
If the LAN network is already con-
figured using the TCP/IP protocol, input
the same network IP address.
Check if the LAN network is already configured using the TCP/IP protocol accord-
ing to the following procedure.
1. Click the Start button, select Programs and Command Prompt.
2. C:\> will be displayed on screen. Enter “IPCONFIG /ALL” and press the Enter key.
3. If the following is displayed in the IP Address filed, no LAN network is configured yet.
"0.0.0.0."
7
Restart Windows NT 4.0.
The TCP/IP protocol in the setting PC is active.
