User’s Manual 2-4
The Grand Tour
Left side
The following figure shows the computer's left side.
* The availability of this feature is dependent on the model you purchased.
The left side of the computer
Fan Vents* The fan vents help prevent the GPU from
overheating.
(The avaliability of this function is dependent on
the model you purchased.)
To prevent possible over heating of the CPU, never block the fan vents.
Security Lock An optional security cable attaches to this port in
order to anchor your computer to a desk or other
large object to deter theft.
1. DC IN 19V Jack
2. RGB Monitor Port
3. Fan Vents
4. Lan Jack
5. Universal Serial Bus (USB) Port
6. TV Out Port
7. HDMI Port
8. i.LINK (IEEE1394a) Port*
9. Express Card Slot
1 3 4 5 6 2 8 9 7
DC IN 19V Jack The DC IN jack is where you plug in the AC
adapter.
RGB Monitor Port This 15-pin port lets you connect an external
video display to the computer.
Fan Vents The fan vents help prevent the CPU from
overheating.
To prevent possible over heating of the CPU, never block the fan vents.
LAN Jack This jack lets you connect to a LAN. The adapter
has built-in support for Ethernet LAN (10 megabits
per second, 10BASE-T), Fast Ethernet LAN
(100 megabits per second, 100BASE-TX) and
Gigabit Ethernet LAN (1000 megabits per second,
1000BASE-T). Two indicators built into the jack let
you see the LAN status.
