Connecting 42
En
C
onnec
ting
2
WPS setup (Wi-Fi Protected Setup)
(MCS-838/MCS-434/MCS-FS232 only)
WPS connection setting
:36LVDEEUHYLDWLRQRI:L)L3URWHFWHG6HWXS
$VWDQGDUGHVWDEOLVKHGE\WKH:L)L$OOLDQFH
industry group for a function allowing settings
UHODWHGWRLQWHUFRQQHFWLRQRI:36FRPSDWLEOH
wireless LAN devices and encryption to be
made with simple operations.
This unit supports push-button configuration
and PIN code configuration.
PBC (Push Button Configuration)
Connection settings are made automatically
VLPSO\E\SUHVVLQJWKH:36EXWWRQVRQWKH
:36FRPSDWLEOHZLUHOHVV/$1GHYLFH7KLVLV
the simplest way of making the settings, and
LVSRVVLEOHZKHQWKH:36FRPSDWLEOHZLUHOHVV
/$1GHYLFHLVHTXLSSHGZLWK:36EXWWRQ
PIN Input
Connection settings are made by inputting the
8-digit PIN code shown on the main display to
the access point to which you selected. Follow
the instructions shown in Connecting using
PIN code configuration on the right.
:KHQSHUIRUPLQJZLUHOHVVVHWWLQJVVHW[Initial
Setup]
A [Network] A [Interface] to [Wireless].
1. Press HOME MENU.
The HOME MENU screen is displayed.
2. Use cursor buttons to select [Initial
Setup] and press ENTER.
The Initial Setup screen is displayed.
3. Select [Initial Setup] A [Network] A
[Wireless Setting] A [Next Screen] and
press ENTER.
A confirmation screen is displayed.
4. Use / to select Yes, then press
ENTER.
The Wireless Setting screen is displayed.
5. Use / to select Auto, then press
ENTER.
The WPS (Wi-Fi Protected Setup) screen is
displayed.
6. Use / to switch between [ PBC] or
[ PIN] screens.
:KHQFRQQHFWLQJXVLQJ3%&JRWRVWHS
:KHQFRQQHFWLQJXVLQJ3,1JRWRVWHS
7. When connecting using PBC (Push
Button), on the [ PBC] screen use /
to select NEXT, then press ENTER.
7KHQSUHVVWKH:36EXWWRQRQWKHDFFHVV
point within 120 seconds.
8. When connecting using PIN confirm
the PIN Code on the [ PIN] screen. Use
cursor / to select NEXT, then press
ENTER.
9. Enter into the access point the PIN
Code that you confirmed in step 8
above.
The PIN Code input method differs
depending on the LAN device used. For
details, consult the operating instructions
accompanying your LAN device.
