bizhub 423/363/283/223 2-6
2.2 Main Body 2
The illustration above shows the main unit with the optional Reverse Automatic Document Feeder DF-621
and Paper Feed Cabinet PC-208.
No. Name
13 Left Cover Release Lever
14 Left Cover
15 Lateral Guide
16 Original Tray
17 Original Output Tray
18 Sub Power Switch
19 Auto Duplex Unit Lock Release Lever
20 Top Right Door
21 Auto Duplex Unit
22 Top Right Door Release Lever
23 Bottom Right Door
24 Bottom Right Door Release Lever
25 Tray 4/Storage Box
26 Tray 3
27 Status Indicator
13
14 15 16
17
18
20
22
23
25
26
27
24
19
21
