CS5376A
86 DS612F4
23.2 Digital Filter Registers
The CS5376A digital filter registers control hardware peripherals and filtering functions.
Name Addr. Type # Bits Description
CONFIG 00 R/W 24 Hardware Configuration
RESERVED 01-0D R/W 24 Reserved
GPCFG0 0E R/W 24 GPIO[7:0] Direction, Pull-Up Enable, and Data
GPCFG1 0F R/W 24 GPIO[11:8] Direction, Pull-Up Enable, and Data
SPI2CTRL 10 R/W 24 SPI2 Control
SPI2CMD 11 R/W 16 SPI2 Command
SPI2DAT 12 R/W 24 SPI2 Data
RESERVED 13-1F R/W 24 Reserved
FILTCFG 20 R/W 24 Digital Filter Configuration
GAIN1 21 R/W 24 Gain Correction Channel 1
GAIN2 22 R/W 24 Gain Correction Channel 2
GAIN3 23 R/W 24 Gain Correction Channel 3
GAIN4 24 R/W 24 Gain Correction Channel 4
OFFSET1 25 R/W 24 Offset Correction Channel 1
OFFSET2 26 R/W 24 Offset Correction Channel 2
OFFSET3 27 R/W 24 Offset Correction Channel 3
OFFSET4 28 R/W 24 Offset Correction Channel 4
TIMEBRK 29 R/W 24 Time Break Delay
TBSCFG 2A R/W 24 Test Bit Stream Configuration
TBSGAIN 2B R/W 24 Test Bit Stream Gain
SYSTEM1 2C R/W 24 User Defined System Register 1
SYSTEM2 2D R/W 24 User Defined System Register 2
VERSION 2E R/W 24 Hardware Version ID
SELFTEST 2F R/W 24 Self-Test Result Code
