Page 40
CS1630/31
40
DS954F3
6.27 Configuration 45 (Config45)
–
Address 77
6.28 Configuration 46 (Config46)
–
Address 78
7
6
5
4
3
2
1
0
-
-
-
-
-
-
VDIFF_LAT
MAX_CUR
Number
Name
Description
[7:2]
-
Reserved
[1]
VDIFF_LAT
Selects if the V
Diff
fault is to be a latched type fault.
0 = Unlatched fault
1 = Latched fault
[0]
MAX_CUR
Configures the second stage to draw maximum power when the boost output
voltage exceeds boost overvoltage protection threshold V
BST
>
V
BOP(th)
, trig-
gering a boost overvoltage fault.
0 = Disable
1 = Enable
7
6
5
4
3
2
1
0
-
-
-
-
WAKEUP3
WAKEUP2
WAKEUP1
WAKEUP0
Number
Name
Description
[7:4]
-
Reserved
[3:0]
WAKEUP[3:0]
Configures the 8-bit code value corresponding to temperature threshold
Temp
Wakeup
. Upon power-up the system will enter an external overtempera-
ture fault disabling the power train, unless the external temperature measured
at the external NTC is below Temp
Wakeup
. If the temperature drops below this
threshold, the device will clear all overtemperature faults. The setting is an off-
set to Temp
eOTP
(see “Configuration 59 (Config59) – Address 91” on page 48
for configuring Temp
eOTP
).
The equation above is setting 8-bit code, CODE
TEMPWakeup
, corresponding to
temperature Temp
Wakeup
, which is in degrees Celsius. The wakeup tempera-
ture code is configured as an offset from the eOTP temperature code and the
shutdown temperature code is configured as an offset from the wakeup tem-
perature code; Temp
eOTP
< Temp
Wakeup
< Temp
Shutdown
.
CODE
TEMPWakeup
CODE
TEMPeOTP
WAKEUP
+
[3:0] 4
=
