Wall Plate and Switcher Compatibility
22
To ground a wall plate:
1. Connect the Ring Tongue terminal to the building grounding point wire (it is
recommended to use a green-yellow AWG#18 wire, crimped with a proper
hand-tool).
2. Insert the M3x6 screw through the toothed lock washers and the tongue
terminal in the order shown above.
3. Insert the M3x6 screw (with the two toothed lock washers and ring tongue
terminal) into the grounding screw hole and tighten the screw.
8 Wall Plate and Switcher Compatibility
Table 17 lists which wall plates are compatible with the SV-551 and SV-552
switchers.
Table 17: Wall Plate and Switcher Compatibility
Wall Plate SV-551 SV-552
301 √ √
(without EDID support)
301xl √ √
(with built-in EDID)
302 √ √
303 √
304 √
305 √
306 √
(with EDID PassThru
and HDCP support)
307 √
9 Summary of Recommended Cables
Table 18 defines the cables that are compatible with the wall plates.
Table 18: Kramer Wall Plate Cable Compatibility
Item Description
SV-301 Cable set
CP-STP-50/C-STP-50 (2 cables 1 ) 2 STP cable 50' (15.24m)
C-MGM/MGM-3 (1 cable) 3 Molded Micro VGA to VGA cable 3' (0.91m)
SV-301xl Cable set
1 There are two types of STP cable recommended for the SummitView™ Kit: XXP-XXX (plenum rated for the SummitView™ US) or
XX-XXX (non-plenum for the SummitView™ Europe)
2 Connects the Wall Plate to the SV-552
3 Connects the SV-551/SV-552 to the projector
