Wiring the Rear Wall Plate Connectors
19
6 Wiring the Rear Wall Plate Connectors
STP cabling of 50' (15.24m) 1 in length is provided (SV-301/302) with the Kramer A/V
SummitView™ Kits 2
Note: For cabling the SV-306 and SV-307 wall plates, use either Kramer
BCP-DGKat524 or BCP-DGKat623 (see Section
. When required, longer STP cabling can be used when purchased for
standalone wall plates but we recommend a maximum transmission range of up to 100'
(30.48m). Exceeding the recommended distance may result in reduced image quality.
9.1 ).
This section describes how to connect the rear panel for the:
•
US wall plate versions (see Section 6.1
• European wall plate versions (see
)
Section 6.2 )
1 Plenum-rated for the SummitView™ US version; non-plenum for the SummitView™ Europe
2 Or should be purchased separately for a standalone machine, see
Table 18 for reference
