Technical Specifications
49
49
13 Technical Specifications
Table 6 includes the technical specifications:
Table 6: Technical Specifications
1
INPUTS:
of VS-162AVM
Video: 16 composite video 1 Vpp/75Ω on BNC connectors
Audio: 16 balanced audio 10kΩ on detachable terminal block connectors
OUTPUTS: Video: 16 composite video 1 Vpp/75Ω on BNC connectors
Audio: 16 balanced audio 50Ω on detachable terminal block connectors
MAX. OUTPUT LEVEL: Video: 2.2 Vpp; Audio: 20dBm
BANDWIDTH (-3dB):
Video: 90 MHz; Audio: >100 kHz
DIFF. GAIN: <0.18%
DIFF. PHASE: ± 0.4 Deg.
K-FACTOR: <0.05%
S/N RATIO: Video: 76dB; Audio: 82dB, unweighted
CROSSTALK (all hostile): Video: <-46dB @ 5MHz; Audio: -80dB @ 1kHz
CONTROLS:
41 selector switches; RS-232, RS-485, IR remote, dry keyboard extension, 3.5"
LCD preview display, 1/4" headphone output with volume dial
COUPLING: Video: DC; Audio: AC
AUDIO THD + NOISE: 0.04% @ 1kHz
AUDIO 2 nd HARMONIC: 0.002%
POWER: 100-240V AC, 50/ 60Hz, Imax=400mA, 31VA
DIMENSIONS: 19” x 7” x 2U W, D, H rack-mountable
WEIGHT: 3.7 kg (8.2 lbs) approx.
ACCESSORIES: Power cord, null-modem adapter, Windows ® -based Kramer control
software, rack “ears”
14 Communication Protocol
Table 7 lists the Protocol 2000 2 hexadecimal codes 3
1 Specifications are subject to change without notice
. The communication
parameters are: 9600 baud, with no parity, 8 data bits and 1 stop bit.
2 Full details are available on our Web site: www.kramerelectronics.com
3 This example assumes MACHINE # 1, and node 0
