MENU Commands

38

11.3 Choosing the SWITCHING METHOD Setting

Section

11.3.1

describes the SWITCHING METHOD settings for

standalone units and large matrices. Section

11.3.2

describes how to

configure a SWITCHING METHOD.

11.3.1 Understanding the SWITCHING METHOD Settings

Setting the unit as a Stand-Alone UNIT provides a choice of three

SWITCHING METHOD settings:

NoVIS - switching occurs immediately after completion of front

panel or dry-contact operation or immediately after receiving an

RS-232 or RS-485 command, or an IR command. The switching

is independent of the vertical reference

EXT (external sync) - switching occurs during the vertical

interval of the video reference signal connected to the IN SYNC

1

connector (this signal should be properly terminated via the

TERM button

2

INT# 1 (internal sync) - switching occurs during the vertical

interval of the video reference signal connected to IN # 1

)

Setting the unit as a Large Matrix (instead of as a Stand-Alone UNIT) provides

a choice of 4 SWITCHING METHOD settings:

NoVIS, EXT or INT# 1 (as described above)

MTX (SYNC from Matrix) - the vertical interval of the video

reference (selected on one unit in the Large Matrix system) is

present on the “SYNC” RS-485 terminal block connector

3

To choose the MTX (SYNC from Matrix) setting

. This

reference signal applies to all switchers in the multi-switcher

system and facilitates switching all VS-162/VS-1616 series units

simultaneously

4

Figure

17

as the example in

illustrates:

Connect the RS-485 terminal block connectors

5

Connect and set the video reference signal on one of the video

units to EXT (external sync) or INT# 1 (internal sync)

between each

switcher in the multi-switcher system

1 Item 1 in

Figure 1

2 Item 3 in

Figure 1

3 Item 5 in

Figure 1

4 This sets the matrix sync configuration from another (Master) machine
5 Via a straight connection of all 4 PINS
