Operating Your VS-162AVM
28
flashing digits 00 appear in the MATRIX display.
The STATUS display shows the message:
out # x
Where x is the output number
2. Press the appropriate IN button.
The MATRIX display shows the 2 flashing digits, representing the input
number and the TAKE LED flashes.
The STATUS display shows 1
out # x
from in # y
the message:
Where x is the output number and y is the input number
3. Press the second appropriate OUT button, repeating step 1 above.
4. Press the appropriate
2
5. Continue with this OUT-IN button sequence, pressing the appropriate OUT
and IN buttons, as required. You can also combine an OUT-OFF or OFF-
OUT combination with this sequence.
IN button, repeating step 2 above.
6. After completing the sequence, press the TAKE button to confirm the
actions.
The inputs switch to the respective outputs, as the MATRIX display shows
(no digits flash) and the TAKE LED lights.
10.6.3 Switching One Input to All Outputs
To switch one input to all the outputs (in the AT ONCE mode):
1. Press the ALL button.
The MATRIX display shows all the sets of 2 flashing digits (each
representing the present input number for that respective output) flashing
simultaneously.
The STATUS display shows the message:
all OUTs
2. Press the appropriate IN button.
This input switches to all the outputs and the MATRIX display shows the
identical non-flashing 2 digits (representing that input number).
To switch one input to all the outputs (in the CONFIRM mode, (the TAKE
LED is lit)):
1 Continuously, within the limit of the timeout (approximately 30 seconds)
2 That corresponds with the second OUT button
