52 VP-460 - The VP-460 RS-232 Communication Protocol
1st
Level
2nd Level 3rd Level 4th Level Range Func. Note
1080p25 30
N\A 31
N\A 32
640X480@60 33
N\A 34
N\A 35
N\A 36
640x480@72 37
640x480@75 38
848x480@60 39
640x480@85 40
N\A 41
800x600@56 42
800x600@60 43
N\A 44
800x600@72 45
800x600@75 46
800x600@85 47
1024x768@60 48
1360x768@60 49
1280x768@60 50
1024x768@70 51
1024x768@75 52
1280x800@60 53
1024x768@85 54
1400x1050@60 55
1400x1050@75 56
1440x900@60 57
1152x864@75 58
1600x900@60 59
1280x1024@60 60
1280x1024@75 61
1280x960@85 62
1920x1200@60RB 63
1280x1024@85 64
1600x1200@60 65
1680x1050@60 66
NONE 0XF5 or 0XFF
OSD Window Control Main Win 0 721 When in the single
window mode, only
Main Win is valid
PiP Win 1
H Position 0:2047 722 The value range is
dynamic, FW
prevents exceeding
of boundaries
V Position 0:2047 723
Transparency ON 1 724
OFF 0
Transparency 0.1:1.6 725
