VP-460 - The Display Modes 33
33
The dual window mode appears in the following preset PiP configurations:
Picture-in-Picture, with a smaller PiP
window superimposed over a full main
window image
Picture + Picture, where both images
appear side-by-side and the aspect
ratios of both images are maintained
Split, where both images are placed
side-by-side with the same height
The window customization feature (see Section 5.2 ) lets you customize the dual
window mode layout (main window and PiP window) to any size.
You can superimpose any input type over any or the same input
type except for the limit below:
Note that you cannot superimpose PC over CV or CV over PC.
