VP-460 - The VP-460 RS-232 Communication Protocol 45
45
Operation commands
Command Syntax Response
update execute*
Reset configuration
to factory default
FACTORY FACTORY RESULT
Set SN # FCT-SN SN# FCT-SN SN# RESULT
Audio/video common commands
Command Syntax Response
Output volume VOLUME VOLUME-
PARAMETER
VOLUME VOLUME-
PARAMETER RESULT
Get output volume VOLUME? VOLUME VOLUME-VALUE
Parameters Description:
VOLUME-PARAMETER = output volume parameters:
[VALUE] either positive or negative digits (minus sign precedes negative values).
“+” increase current value,
“-“ decrease current value
Win-customization
WIN-CUST WINDOW, HPOS,
HW , VPOS, VH
WIN- CUST WINDOW, HPOS,
HW , VPOS, VH RESULT
Parameters Description: fast window customization
[WINDOW] “0” for main window; “1” for PiP window
[HPOS] horizontal position value
[HW] horizontal width value
[VPOS] vertical position value
[VH] vertical height value
Set dual window state
PIP PIP-MODE PIP PIP-MODE RESULT
Get dual window state PIP? PIP PIP-MODE
Parameters Description:
PIP-MODE = Dual window state:
"0" or "off" for single window.
"1" or "on" to for dual window.
Identification commands
Command Syntax Response
Protocol
Handshaking
#CR ~OK CRLF
Read device model MODEL? MODEL MACHINE_MODEL
Read device serial
number
SN?
SN SERIAL_NUMBER
Read device
firmware version
VERSION? VERSION MAJOR .MINOR
.BUILD .REVISION
Read device
build date
BUILD-DATE? BUILD-DATE YYYY/MM/DD
HH:MM:SS
Read device
protocol
PROT-VER? PROT-VER 3000:MAJOR
