VP-460 - The Display Modes 35
35
6.2.3 Selecting the PIP Source
To select a PiP source you have to set the VP-460 to any of the PiP display mode
configurations and then select the desired input.
6.2.3.1 Selecting the PiP Source via the Front Panel Buttons
Press and hold the PIP front panel button while pressing the input button of the
required PiP source.
For example, to select SDI as the PiP source over PC as the main source, press
the PIP front panel button while pressing the SDI front panel button.
In this example, the PC button is illuminated and the SDI button blinks
When selecting, for example, PC to be both in the background and as the PiP
source (see
Figure 22 ), press the PC input button while the PIP button is not
selected (the button is illuminated) and then press the PIP button to enter the PiP
mode. Press and hold the PIP button while pressing the PC input button.
In this example, the PC is illuminated first and then blinks after selecting it again as the PiP
source
Figure 22: PC 1 superimposed over PC 1
6.2.3.2 Selecting the PiP Source via the IR Remote Control Transmitter
Press the PIP button on the IR transmitter (the PIP front panel button is
illuminated). Press the desired PiP source button on the IR transmitter (see
Section
7.3 ).
