8 VP-460 - Connecting the VP-460
4 Connecting the VP-460
Always switch off the power to each device before connecting it to
your
VP-460. After connecting your VP-460, connect its power and
then switch on the power to each device.
You do not have to connect all the inputs and outputs, connect only
those that are required.
To connect the VP-460, as illustrated in the example in Figure 2 , do the following:
1. Connect a computer graphics source to the PC IN VIDEO 15-pin HD INPUT
connector.
2. Connect a composite video source (for example, a composite video player)
to the CV IN VIDEO INPUT RCA connector.
3. Connect an SDI source (for example, an SDI digital camera) to the SDI IN
VIDEO INPUT BNC connector.
4. Connect the audio input signals to the AUDIO IN connectors: PC IN (3.5mm
mini jack) and CV IN (RCA connectors), as required (not shown in Figure 2 ).
5. Connect the HDMI OUT connector to an HDMI acceptor (for example, a
plasma display).
6. Connect the SDI LOOP BNC connector to an SDI monitor (for example, an
SDI display).
7. Connect the SDI OUT BNC connector to an SDI acceptor (for example, an
SDI display with speakers).
8. Connect the S/PDIF OUT RCA connector to an audio acceptor (for example,
a receiver), not shown in Figure 2 .
9. If required, you can connect a PC and/or controller to the RS-232 terminal
block (see Section 7.2.1
!
)
