VP-460 - Technical Specifications
41
41
9
Technical Specifications
INPUTS:
1 VGA on a 15-pin HD connector
1 composite video (1V/75Ω
)
on an RCA connector
1 SDI on a BNC connector
1 PC IN unbalanced stereo audio (1Vrms nom/100kΩ) on a 3.5mm mini jack
connector
1 L and R unbalanced stereo audio ((1Vrms nom/100kΩ) on 2 RCA connectors
OUTPUTS:
1 SDI on a BNC connector
1 HDMI (deep color) connector
1 S/PDIF digital audio on an RCA connector
COMPLIANCE
WITH HDMI
STANDARD:
Supports HDMI (deep color)
OUTPUT
RESOLUTIONS:
640x480@60, 640x480@75, 800x600@50, 800x600@60, 800x600@75,
1024x768@50, 1024x768@60, 1024x768@75, 1280x768@50, 1280x768@60,
1280x800@60, 1280x1024@50, 1280x1024@60, 1280x1024@75, 1360x768@60,
1366x768@50, 1366x768@60, 1400x1050@50, 1400x1050@60, 1600x900@60,
1600x1200@50, 1600x1200@60, 1680x1050@60, 1920x1200@60, 480i60,
480p60, 576i50, 576p50, 720p50, 720p59.94, 720p60, 1080p23.976, 1080p24,
1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 2K50, 2K60
CONTROLS:
Front panel buttons, OSD, IR remote control, RS-232 on a 9-pin D-sub connector
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F) 40°C
STORAGE
TEMPERATURE:
-40° to +70°C (-49° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
POWER
CONSUMPTION:
5V DC 2.90A
DIMENSIONS:
21.5cm x 16.3cm x 4.4cm (8.5" x 6.4" x 1.7") W, D, H
WEIGHT:
0.9kg (1.98lbs) approx.
ACCESSORIES:
Power adapter (5.2V / 4A), IR remote control
OPTIONS:
RK-1 rack adapter
Specifications are subject to change without notice
For the most updated resolution list, go to our Web sit
