Kramer Electronics VP-460 User Manual
Page 19
14
VP-460 - The OSD Menu
Setting
Function
Input Settings
Set the:
H Image Shift – to set the horizontal position of the image within the
window
M
/
P
Volatile parameter
V Image Shift – to set the vertical position of the image within the
window
M
/
P
Volatile parameter
Auto Positioning – to search the input image during the tuning process
and automatically position it on the output window in a perfect fit.
Set to Off to disable auto positioning
Set to Normal Scan to perform a normal range image search
Set to Wide Scan to perform a wide range image search
M
/
P
In the Normal/Wide Scan option, the machine automatically adjusts the PC
input video resolution. For the other inputs, the machine automatically adjusts
all the input video resolutions except for HD/SD (CEA 861 standard) video
resolutions
HDCP Mode –N/A
EDID Select – to select the native resolution on each input to be read by
the video source connected to that input: 1024x768@60, 1280x800@60,
1280x1024@60, 1366x768@60, 1440x900@60, 1400x1050@60,
1600x900@60, 1600x1200@60, 1680x1050@60, 1920x1200@60RB,
720p50, 720p60, 1080p50, 1080p60, 2K50 or 2K60
Color Space – to select the color space for the PC input: RGB, YPbPr or
Follow Input
If the machine is set to the dual display mode, and the both
the Main and PiP windows display the PC input, set the same
input color space value for both windows
Window
Customization
Select the position and the size of the selected window: H Position, H
Width, V Position and V Height (see
Section 5.2.1.2
and
Section
The value range is dynamic. The FW prevents windows from exceeding the
boundaries or over-sizing. The position and size of the windows are saved to
the system.
M
/
P
The size and position of the customized window (main or PiP) remain valid
even when toggling the PIP button (front panel, Remote control transmitter or
protocol command).
The customized setup is cancelled only by explicitly selecting a preset Display
Mode (see first item in this table) or if a new customized setup is created.
Use the front panel + and – buttons or the IR remote control transmitter to set
the position and height of the Main and/or PiP windows
The PiP window maximum horizontal active image area is
1600 pixels
The display mode setup, shown in
, is part of the entire system control and
the selected Single Window also shows the current aspect ratio (Best Fit):
